Dark Green 40*40mm Galvanized Chain Link Fence for Forest Protecting and Building Site
1.Description
- Using high quality iron rod as raw material,galvanzied,or galvanzied and PVC/PE coating,it can resisit the corrosive and ultraviolet radiation very strongly.
- The thickness of PVC powders coating usually can reach above 1.0mm.
- The fence obtains very strong powers to resist the concussion.
- Generally,the smaller the diamond size,the stronger the fence.
- The ends of the fence usually have two kinds.One is knuckles barb,the other one is twisted barb.
2.Surface Treatment
Using high quality iron rod as raw material,galvanzied,or galvanzied and PVC/PE coating,it can resist the corrosive and ultraviolet radiation very strongly. At the top,it can use barbe dwire or razor wire,to enlarge the safety.
| Surface Treatment | Min. | Max. |
| Electric Gal. | 15g/m² | 25g/m² |
| Hot Dipped Gal. | 30g/m² | 366g/m² |
| PVC/PE Dipped Coating | 400microns | 600microns |
3.Popular Specification
| Wire Dia. | Mesh | Length | Height | Post's Height | Suitable Post |
| 1.8mm 2.0mm 2.5mm 3.0mm 3.5mm 4.0mm 4.5mm | 35*35mm 40*40mm 50*50mm 60*60mm 75*75mm 100*100mm | 10m 15m 20m 25m 30m Or Longer | 1000mm 1200mm 1500mm 1800mm 2000mm 2500mm 3000mm 4000mm 5000mm | 1500mm 1700mm 2000mm 2300mm 2500mm 3000mm 4000mm 5000mm 6000mm | Round Tubes Dia. 40,48,50,63,76mm Mushroom Post Model No. XLFP-03 "Y"Post Model No.XLFP-07 "T"Post Model No.XLFP-08 Or with the frame to install with the post |
4.Standard Colors
- Only Galvanized
- Dark Green RAL6005
5.Feature
- The wire are linked,it is easy to produce any width and length.The Max.Height can till 5m or more,the length can be adjusted as the needs.
- This kinds of mesh is not easy to climb,and suitble for using large quantity.
- The post used is very portable.It reduces the cost of the whole fence and can last long time.
6.Application
- Playground(Tennis Ground,Football Ground,Basketball Ground)
- Building Site
- Countryard,Park,Lawn,Forest Protection
7.Our Company
Anping Xinlong wire mesh manufacture co.,LTD established in 1989. We always insist on the policy of HONESTY, we always honest to our customers. We are manufacture and we are professional at welded wire mesh(roll/panel), iron wire, barbed wire, razor blade wire, welded wire mesh fence,Gabion mesh,We equiped our own PVC coating equipment at 2007, so that our production can be produce by ourselves, improve our productivity and reduce our cost so that we can give our customers best price.We sincerely hope to seek mutual benefit and development the relationship with our clients.
We treat Quality first, we believe this can give us chance to trust each other, then, the price, we promise give our best price to our customers which means mutual benefit, at the same time, we also offer the best service to you!
